TEE STD DN 6" WP5

Rau cov lus qhia tshwj xeeb uas tau muab rau "TEE STD DN 6" WP5, cia peb faib cov ntsiab lus:

Kev sib xyaw:

WP5 Alloy hlau:

Cov pa roj carbon (C): 0.15% siab tshaj

Manganese (Mn): 0 30-0.60%

Phosphorus (P): 0.025% siab tshaj

Sulfur (S): 0.025% siab tshaj

Silicon (Si): 0 50-1 00%

Chromium (Cr): 4.00-6 {2}}%

Molybdenum (Mo): 0 45-0.65%

Lwm cov ntsiab lus: Feem ntau suav nrog me me ntawm vanadium, nitrogen, thiab tungsten.

Mechanical Properties:

Tensile zog: 415-585 MPa (60-85 ksi)

Yield zog: 205 MPa (30 ksi) yam tsawg kawg nkaus

Elongation: 20% yam tsawg kawg nkaus

Hardness: Nws txawv nyob ntawm qhov kev kho cua sov thiab cov alloy muaj pes tsawg leeg.

Daim ntawv thov:

Feem ntau siv rau hauv cov kav dej uas yuav tsum tau muaj qhov kub thiab txias siab, xws li hauv cov chaw tsim hluav taws xob, cov chaw tsim khoom, thiab cov nroj tsuag petrochemical.

Haum rau conveying ntau yam kua thiab gases ntawm qhov kub thiab txias siab.

TEE STD DN 6 "WP5 tuaj yeem siv rau kev txiav tawm cov kav dej hauv peb txoj kev sib txuas.

Q&A:

Q: "STD" qhia dab tsi hauv kev xaiv?

A: "STD" stands rau tus qauv, qhia tias lub tee ua raws li tus qauv qhov ntev thiab qhov tshwj xeeb.

Q: WP5 alloy steel fittings puas tuaj yeem siv rau hauv ib puag ncig corrosive?

A: Yog, WP5 alloy steel muaj qhov zoo corrosion kuj, tshwj xeeb tshaj yog nyob rau hauv high-temperature puag ncig uas nws tsim ib tug tiv thaiv oxide txheej.

Q: Dab tsi yog qhov tseem ceeb ntawm DN 6 "?

A: DN 6 "yog hais txog lub nominal txoj kab uas hla ntawm lub tee, uas yog 6 ntiv tes.

Q: Puas yog WP5 alloy steel fittings weldable?

A: Yog, WP5 alloy steel fittings tuaj yeem welded siv cov txheej txheem vuam tsim nyog thiab cov ntaub ntawv muab tub lim haum rau cov hlau alloy.

Cov lus teb no muab kev nkag siab txog cov khoom xyaw, cov khoom siv kho tshuab, kev siv, thiab cov lus nug uas muaj feem xyuam nrog "TEE STD DN 6" WP5".
